1. Inngangur og yfirview
The AWANFI J120 is a versatile and powerful portable jump starter designed to provide reliable starting power for a wide range of vehicles. Beyond its primary function, it serves as a portable power bank and features an integrated LED flashlight for emergencies. Its compact and lightweight design ensures easy portability, making it an essential tool for any vehicle owner.
Image 1: AWANFI J120 3000A Portable Jump Starter with included jumper cables.
2. Hvað er í kassanum
- 1 × AWANFI J120 3000A Jump Starter
- 1 × Heavy-Duty Battery Clamps (Smart Jump Cable)
- 1 × USB Type-C hleðslusnúra
- 1 × Waterproof Storage Case
- 1 × User Guide for Jump Starter
- Upplýsingar um 3 ára takmarkaða ábyrgð
Image 2: All items included in the AWANFI J120 Jump Starter package.
3. Vörueiginleikar
3.1. Ultra-Effective Jump Starting
- Toppur núverandi: 3000 Amps, capable of starting engines up to 10.0L Gas or 8.0L Diesel.
- Fjölhæf notkun: Can start cars, trucks, motorcycles, snowmobiles, ATVs, UTVs, lawnmowers, and yachts.
- Intelligent Safety Protections: Equipped with 10 safety features including over-charge, reverse-polarity, short-circuit, over-current, low-temperature, over-voltage, high-temperature, spark-proof, over-load, and reverse-charge protection.
- Rekstrar við öfgahita: Performs flawlessly in temperatures ranging from -4℉ to 140℉.
Image 3: The AWANFI J120 Jump Starter connected to a vehicle battery for jump starting.
3.2. Multi-Function Power Bank
- Tvöfalt USB úttak: Includes one USB 5V/9V/12V Quick Charge port and one USB 5V/2.4A port.
- Hleðsla tækis: Capable of charging smartphones, tablets, and other USB-powered devices.
Image 4: The AWANFI J120 Jump Starter functioning as a portable power bank.
3.3. Integrated LED Flashlight
- 3 ljósastillingar: Features Flash Light, Strobe Light, and SOS Light modes.
- Fjölhæf notkun: Tilvalið fyrir camping, emergencies, outdoor adventures, and travel.
Image 5: The integrated LED flashlight of the AWANFI J120 Jump Starter.
3.4. Ultra-Portable Design
- Litlar stærðir: Measures 8.46 x 3.14 x 1.18 inches.
- Léttur: Weighs 1.39 pounds.
- Þægileg geymsla: Easily fits in a car emergency kit, glove box, or bag.
3.5. Designed for Ultimate Reliability
- Langur líftími: Guarantees over 5000+ recharge cycles.
4. Uppsetning
4.1. Hleðsla ræsibúnaðarins
Before first use, fully charge the AWANFI J120 Jump Starter. Use the provided USB Type-C charging cable to connect the jump starter to a compatible USB power source (e.g., wall adapter, car charger, computer USB port). The digital display will show the charging progress.
Image 6: Various methods for charging the AWANFI J120 Jump Starter.
5. Notkunarleiðbeiningar
5.1. Að ræsa ökutæki
- Ensure the jump starter is sufficiently charged (above 30% recommended).
- Insert the smart jump cable plug firmly into the jump starter's EC5 port.
- Tengdu rauða (+) clamp við jákvæða (+) pól rafgeymisins í bílnum.
- Tengdu svarta (-) clamp við neikvæða (-) skaut rafgeymisins.
- Observe the indicator light on the smart jump cable. A solid green light indicates it's ready to jump start.
- If the indicator light shows an error (e.g., flashing red for reversed polarity, flashing yellow for low voltage), refer to the Troubleshooting section.
- If the vehicle battery is extremely low, press the
