Cuisinart FP-11SVP1

Cuisinart Elemental 11-Cup Food Processor (FP-11SV)

Leiðbeiningarhandbók

1. Uppsetning og samsetning

Before first use, wash all removable parts in warm, soapy water or in the dishwasher. Ensure the motor base is unplugged from the power outlet.

1.1 Assembling the Work Bowl and Blade

  1. Setjið mótorstöðina á hreint, þurrt og slétt yfirborð.
  2. Position the 11-cup work bowl onto the motor base, aligning the handle with the front of the base. Turn the work bowl clockwise until it locks into place.
  3. Carefully place the desired blade or disc onto the stem inside the work bowl. For chopping, use the S-shaped chopping/mixing blade. For slicing or shredding, use the appropriate disc. Caution: Blades and discs are extremely sharp. Handle with care.
  4. Place the work bowl cover onto the work bowl, aligning the feed tube with the work bowl handle. Turn the cover clockwise until it locks into place.
  5. Insert the large pusher into the feed tube. The small pusher can be inserted into the large pusher for smaller ingredients.
Cuisinart Elemental 11-Cup Food Processor assembled on a kitchen counter with grapefruits.

Figure 1: The Cuisinart Elemental 11-Cup Food Processor fully assembled on a kitchen counter.

Cuisinart Elemental 11-Cup Food Processor with various blades and accessories laid out.

Mynd 2: Yfirview of the Cuisinart Elemental 11-Cup Food Processor and its included accessories, including the chopping blade, slicing disc, and shredding disc.

2. Notkunarleiðbeiningar

The Cuisinart Elemental Food Processor features a rubberized touchpad with High, Low, Off, and Pulse controls for versatile food preparation.

2.1 Using the Chopping/Mixing Blade

The stainless steel S-blade is ideal for chopping, mincing, mixing, and pureeing. Place ingredients directly into the work bowl. Secure the lid and pusher. Select the 'High' or 'Low' setting for continuous processing, or use 'Pulse' for controlled chopping.

2.2 Using Slicing and Shredding Discs

The food processor includes an adjustable slicing disc (0-7mm) and a reversible shredding disc (fine/medium). Attach the desired disc to the stem. Place ingredients into the wide-mouth feed tube. Use the large pusher for whole fruits and vegetables, or the small pusher for smaller items. Select 'High' or 'Low' for continuous operation.

Video 1: This video demonstrates the features and operation of the Cuisinart Elemental Food Processor, including the various blades and how to use them for different food preparation tasks.

3. Umhirða og viðhald

3.1 Þrif

  • Taktu alltaf matvinnsluvélina úr sambandi áður en hún er þrifin.
  • All removable parts (work bowl, cover, pushers, blades, and discs) are dishwasher safe (top rack recommended).
  • Til að þrífa mótorbotninn skal þurrka hann með augndropa.amp klút. Ekki dýfa mótorbotninum í vatni eða öðrum vökva.
  • For stubborn food residue, use a small brush to clean the blades and crevices.

3.2 Geymsla

Store the food processor and its accessories in a dry, safe place. Ensure blades and discs are stored securely to prevent accidental injury.

4. Bilanagreining

  • Eining kviknar ekki á: Ensure the work bowl and cover are correctly assembled and locked into place. The safety interlock system prevents operation if not properly secured. Check if the unit is plugged into a working power outlet.
  • Food not processing evenly: For chopping, use the 'Pulse' function for better control and to prevent over-processing. For slicing/shredding, ensure ingredients fit properly in the feed tube and are pushed down evenly.
  • Motor seems strained: Do not overload the work bowl. Process ingredients in smaller batches if necessary. Ensure the blade/disc is free from obstructions.
  • Leakage from work bowl: Verify that the work bowl cover is securely locked and the gasket is properly seated. The SealTight Advantage System is designed to prevent leaks.

5. Tæknilýsing

  • Vörumerki: Matargerðarlist
  • Fyrirmyndarheiti: Elemental matvinnsluvél
  • Gerðarnúmer: FP-11SVP1
  • Skálargeta: 11 bollar
  • Mótor Wattage: 550 vött
  • Vörumál: 8" D x 10.5" B x 15.75" H
  • Þyngd hlutar: 11.5 pund
  • Blaðefni: Ryðfrítt stál
  • Fjöldi hraða: 4 (High, Low, Off, Pulse)
  • Sérstakur eiginleiki: Öruggt í uppþvottavél
  • Mælt er með notkun: Chop, Mix, Puree, Shredder, Slice
Cuisinart Elemental 11-Cup Food Processor with dimensions labeled.

Figure 3: Dimensions of the Cuisinart Elemental 11-Cup Food Processor: 16.2 inches high, 8 inches deep, and 10.4 inches wide.

6. Ábyrgð og stuðningur

This Cuisinart Elemental 11-Cup Food Processor comes with a Takmörkuð 3 árs ábyrgð. For detailed information regarding warranty policies, troubleshooting steps, or customer support, please refer to the complete user manual included with your product or visit the official Cuisinart websíða.
