1. Öryggisleiðbeiningar
- Lesið allar leiðbeiningar vandlega fyrir uppsetningu og notkun.
- Haldið vörunni frá eldi og miklum hitagjöfum.
- Ekki reyna að taka vöruna í sundur eða breyta henni. Það getur ógilt ábyrgðina og valdið skemmdum.
- Ensure the installation surface is stable and can support the weight of the light.
- Avoid placing the solar panel in shaded areas to ensure optimal charging.
- The product contains non-rechargeable batteries. Do not attempt to replace them unless specified by the manufacturer.
2. Innihald pakka
Gakktu úr skugga um að allir íhlutir séu til staðar í pakkanum:
- COLBOR Vintage Outdoor Solar Wall Light (1 or 2 units, depending on purchase)
- E26/E27 LED Bulb (pre-installed or included separately)
- Festingarskrúfur og veggfestingar
- Notendahandbók
3. Vöru lokiðview
The COLBOR Vintage Outdoor Solar Wall Light is designed for efficient and aesthetic outdoor illumination. It features a classic vintage style combined with modern solar technology.
Mynd: Basic Information and Dimensions of the COLBOR Solar Wall Light. Displays work rate (1W), lamp shell material (ABS), human body induction distance (1-5 meters), sensing angle (120 degrees), solar panel specifications (Polysilicon 6.5V/1.5W), bulb specification (DC-3V/1W, E27 LED warm light bulb), bulb interface (E26/E27 universal), charging time (6-8 hours in full sunlight), and applicable scenes.
Mynd: Key Components and Features of the Solar Wall Light. Highlights the 3 solar panels, intelligent motion detector, ON/OFF & Mode button, high-quality ABS material, transparent dust cover, and open-bottom design for easy bulb replacement and cleaning.
Helstu eiginleikar:
- Sólarorkuknúið: Equipped with multi-face solar panels for efficient charging (6-8 hours for full charge).
- Hreyfiskynjari: High-sensitivity PIR motion sensor detects movement within 5 meters at a 120° angle.
- 3 ljósastillingar: Offers versatile lighting options for different needs.
- IP65 vatnsheldur: Constructed from high-quality ABS material, ensuring durability and performance in various weather conditions.
- Skiptanlegur pera: Features an E26/E27 universal interface for easy bulb replacement.
- Auðveld uppsetning: No wiring required, simple 3-step installation.
4. Uppsetning og uppsetning
Follow these steps to install your COLBOR Solar Wall Light:
- Veldu staðsetningu: Select a location that receives direct sunlight for 6-8 hours daily to ensure optimal charging. Avoid areas under eaves or trees that might block sunlight.
- Merkja og bora: Use the light as a template to mark the positions for drilling holes on your wall. Drill holes and insert the provided wall anchors.
- Virkja ljós: Before mounting, locate the ON/OFF button and the Mode button (usually near the motion sensor). Press and hold the ON/OFF button for 3 seconds to turn on the light. Then, press the Mode button to select your desired lighting mode.
- Festu ljósið: Stilltu ljósinu saman við boraðar holur og festu það með meðfylgjandi skrúfum.
Mynd: Installation Steps. Shows drilling holes, inserting plastic expansion anchors, pressing the ON/OFF button to activate, and finally installing the solar light.
Mynd: Optimal Solar Panel Placement. Emphasizes exposing the solar panel to direct sunlight for complete charging and avoiding other light sources shining on the panel at night.
Uppsetning/skipti á peru:
The light uses an E26/E27 universal bulb interface. To install or replace the bulb:
- Gently unscrew the bottom part of the lamp to access the bulb socket.
- Screw in the E26/E27 LED bulb clockwise until secure.
- Festu aftur neðri hluta lamp.
Mynd: Replaceable Bulb Feature. Illustrates the E26/E27 universal bulb interface and examples of compatible bulb types.
5. Notkunarleiðbeiningar
The COLBOR Solar Wall Light features 3 intelligent lighting modes. Press the 'Mode' button to cycle through them:
Mynd: 3 Lighting Modes. Visually explains how each mode functions with motion detection.
- Mode 1 (Dim to Bright): The light stays on at 30% brightness throughout the night. When motion is detected, it switches to 100% brightness for 15 seconds, then returns to 30% brightness.
- Mode 2 (Motion Activated): The light remains off. When motion is detected at night, it turns on at 100% brightness for 15 seconds, then automatically turns off if no further motion is detected.
- Mode 3 (Constant Dim): The light automatically turns on at night and stays on at a constant 30% brightness throughout the night, regardless of motion.
The light automatically turns off during the day and charges via its solar panels.
Mynd: Dusk to Dawn Outdoor Solar Wall Lights. Illustrates the light automatically turning off and charging during the daytime, and turning on and lighting at night.
6. Viðhald
- Þrif: Þurrkið sólarplötuna reglulega með mjúkum, þurrum klút.amp klút til að fjarlægja ryk, óhreinindi eða rusl. Hrein sólarplata tryggir skilvirka hleðslu.
- Skoðun: Periodically check the light for any signs of damage or loose components.
- Skipt um peru: If the LED bulb needs replacement, ensure the light is off and follow the bulb installation/replacement steps in Section 4.
- Rafhlaða: The product uses non-rechargeable AA and lithium-ion batteries. Do not attempt to replace them. Contact customer support if you suspect a battery issue.
7. Bilanagreining
| Vandamál | Möguleg orsök | Lausn |
|---|---|---|
| Ljós kviknar ekki á nóttunni. | Ónóg sólarljós til hleðslu. | Gakktu úr skugga um að sólarsellan fái 6-8 klukkustundir af beinu sólarljósi daglega. Færðu hana ef þörf krefur. |
| ON/OFF button is off. | Press and hold the ON/OFF button for 3 seconds to turn it on. | |
| Sólarrafhlaða er óhrein. | Hreinsaðu yfirborð sólarplötunnar. | |
| Hreyfiskynjari virkar ekki. | Skynjarinn er stíflaður eða óhreinn. | Clear any obstructions and clean the sensor lens. |
| Light is in constant dim mode (Mode 3). | Press the Mode button to switch to Mode 1 or 2 for motion detection. | |
| Light stays dim or turns off quickly. | Insufficient charge due to cloudy weather or poor solar panel placement. | Ensure optimal sunlight exposure. Allow several sunny days for a full charge. |
8. Tæknilýsing
| Eiginleiki | Forskrift |
|---|---|
| Vörumál (L x B x H) | 28 x 23 x 15 cm (10.5L x 10.5W x 22.5H centimeters) |
| Þyngd | 1.07 kíló |
| Efni | Akrýlnítríl bútadíen stýren (ABS), pólýkarbónat (PC) |
| Stíll | Vintage |
| Form fyrir innréttingu | Ljósker |
| Herbergistegund | Útivist |
| Sérstök notkun fyrir vöru | Courtyard, Garden, Patio |
| Inni/úti notkun | Útivist |
| Aflgjafi | Knúið sólarorku |
| IP einkunn | IP65 |
| Samsetning krafist | Já |
| Rafhlöður nauðsynlegar | No (Batteries included are non-rechargeable and integrated) |
| Tegund rafhlöðu | 1 AA battery (non-rechargeable) and 1 Lithium-ion battery (non-rechargeable) |
| Innifalið íhlutir | Outdoor Solar Projector |
| Gerðarnúmer | MOKCL-SW-SW2-SWLC |
9. Media Gallery
Vörumyndbönd
Myndband: Vara lokiðview. This video showcases the COLBOR solar wall light, demonstrating its design and how it illuminates.
Myndband: New Solar Wall Lamps - Decorate Your Yard. This video demonstrates the aesthetic appeal and functionality of the solar wall lights in a garden setting.
Myndband: Outdoor Waterproof Wall Lamp Display. This video highlights the waterproof features of the outdoor wall lamp, showing its resilience to weather conditions.
Vörumyndir
Mynd: Dustproof Cover Design and Good Weather-Proof. Showcases the light's IP65 waterproof, snow-prevention, and heat-resistant features, ensuring durability in various climates.
Mynd: Dustproof Design with 4 Transparent Covers. Compares the product's superior dustproof design, offering better protection against rain, dust, spiders, and insects compared to other designs.
Mynd: Applicable Scenes. Displays the versatility of the light, showing it installed in different outdoor settings such as villas, aisles, and fences, enhancing the ambiance.
10. Ábyrgð og stuðningur
For warranty information or technical support, please refer to the seller's contact details provided at the point of purchase or visit the official COLBOR webvefsíða. Geymið kaupkvittunina sem sönnun fyrir kaupunum.
