1. Inngangur
This manual provides essential information for the safe and efficient use of your PowMr 12V 100Ah LiFePO4 Lithium Battery. This battery is designed for various applications including solar systems, RVs, boats, and off-grid setups, offering a reliable and long-lasting power solution. Please read this manual thoroughly before installation and operation.
2. Öryggisupplýsingar
Always prioritize safety when handling batteries. Failure to follow these instructions may result in serious injury, property damage, or damage to the battery.
- Ekki skammhlaupa rafhlöðuna.
- Ekki láta rafhlöðuna verða fyrir eldi eða miklum hita.
- Do not immerse the battery in water or other liquids. The battery is IP65 waterproof, but prolonged immersion is not recommended.
- Ekki taka í sundur, mylja eða gata rafhlöðuna.
- Notið aðeins samhæf hleðslutæki og hleðsluaðferðir.
- Tryggið góða loftræstingu við hleðslu og afhleðslu.
- Haltu rafhlöðunni fjarri börnum og gæludýrum.
- Notið viðeigandi persónuhlífar (PPE) eins og hanska og augnhlífar þegar rafhlöður eru meðhöndlaðar.
- This battery is not intended for use as a starter battery.
Image: A special reminder icon, emphasizing important safety notes.
3. Innihald pakka
Þegar pakkinn er opnaður skal ganga úr skugga um að allir íhlutir séu til staðar og óskemmdir:
- 1 x PowMr 12V 100Ah LiFePO4 Lithium Battery
- 2 x M8 tengiboltar
- 2 x þvottavélar
Video: Unboxing the PowMr 12V 100Ah LiFePO4 Lithium Battery, showing the battery, terminals, and screws. This video provides a visual guide to the package contents.
Image: The PowMr 12V 100Ah LiFePO4 battery with M8 terminal bolts, illustrating the included hardware.
4. Vörueiginleikar
- Langur endingartími: Offers 4000+ cycles with 100% Depth of Discharge (DoD), providing a service life of up to 10 years.
- Létt hönnun: Weighs approximately 11.5kg, significantly lighter than traditional lead-acid batteries, enhancing portability.
- Innbyggt 100A BMS: Integrated Battery Management System protects against overcharge, overdischarge, overcurrent, and short circuits.
- Stækkanlegt getu: Supports series and parallel connections for increased capacity and voltage (up to 4S4P for max 51.2V and 400Ah).
- Breitt forrit: Hentar fyrir húsbíla, camping, marine, solar systems, home energy storage, and off-grid applications.
- IP65 vatnsheldur: Provides protection against dust and water splashes, suitable for indoor and outdoor installations.
Image: A diagram illustrating the various protections offered by the built-in 100A BMS, including overcharge, overdischarge, overcurrent, short circuit, cell voltage, og vernd gegn háum hita.
Mynd: Sjónræn samanburður sem varpar ljósi á kostitages of the PowMr LiFePO4 battery over traditional lead-acid batteries in terms of weight, cycle life, service life, and depth of discharge.
5. Uppsetning og uppsetning
5.1. Upphafsskoðun
Áður en rafgeymirinn er settur upp skal athuga hann hvort hann hafi einhverjar skemmdir. Gakktu úr skugga um að tengipunktarnir séu hreinir og lausir við tæringu.
5.2. Að tengja rafhlöðuna
Connect the battery to your system using appropriate cables and connectors. Ensure correct polarity: positive (+) to positive and negative (-) to negative. Use the provided M8 terminal bolts to secure connections tightly.
Image: A diagram showing how to connect batteries, indicating positive and negative terminals.
5.3. Röð og samhliða tengingar
The PowMr 12V 100Ah LiFePO4 battery supports both series and parallel connections to achieve higher voltage or capacity. It can be connected in series up to 4 units (4S) and in parallel up to 4 units (4P), allowing for configurations such as 4S4P for a maximum of 51.2V and 400Ah.
- Samhliða tenging: Tengdu jákvæðu og neikvæðu tengi saman til að auka afkastagetuna (Ah) en viðhalda sama rúmmáli.tage (V).
- Röð tenging: Tengdu plúsa pól einnar rafhlöðu við neikvæða pól næstu rafhlöðu til að auka spennuna.tage (V) en viðhalda sömu afkastagetu (Ah).
- Always ensure all batteries in a series or parallel bank are of the same type, capacity, and state of charge before connecting.
Image: A diagram illustrating various expandable capacity configurations, including a 4S4P setup for maximum energy storage.
Image: A schematic showing the PowMr LiFePO4 battery integrated into a solar power system, connecting solar panels, an MPPT controller, and an inverter to power various household loads.
6. Notkunarleiðbeiningar
6.1. Hleðsla
The battery supports a 50A charging current. Use a compatible LiFePO4 charger or a solar charge controller (MPPT recommended) designed for lithium iron phosphate batteries. Ensure the charging voltage er innan ráðlagðs bils (venjulega 14.2V - 14.6V).
Image: A split image showing the battery being charged by a dedicated battery charger on one side and a solar panel setup with an MPPT controller charging the battery on the other.
6.2. Losun
The battery supports a 100A continuous discharge current. The built-in BMS will protect the battery from over-discharge. Ensure your load does not exceed the maximum continuous discharge current to prevent the BMS from triggering protection mode.
6.3. Rekstrarhiti
Observe the recommended operating temperature ranges:
- Hleðsla: 0°C til 50°C (32°F til 122°F)
- Losun: -20°C til 60°C (-4°F til 140°F)
- Geymsla: -10°C til 50°C (14°F til 122°F)
Image: A thermometer graphic indicating the safe operating temperature range for the battery.
7. Viðhald
- Regluleg skoðun: Periodically check the battery terminals for cleanliness and tightness. Ensure there are no signs of damage or swelling.
- Þrif: Use a dry cloth to wipe the battery casing. Notið ekki leysiefni eða slípiefni.
- Geymsla: If storing the battery for an extended period, ensure it is charged to approximately 50-70% State of Charge (SoC) and stored in a cool, dry place within the recommended storage temperature range. Recharge every 3-6 months to prevent deep discharge.
8. Bilanagreining
If you encounter issues with your PowMr LiFePO4 battery, refer to the following common problems and solutions:
| Vandamál | Möguleg orsök | Lausn |
|---|---|---|
| Rafhlaða hleðst ekki | Charger not connected, charger fault, BMS protection triggered (over-discharge, over-voltage, low temperature) | Check charger connection and functionality. Verify charging parameters. Allow battery to warm up if too cold. If BMS is in protection, disconnect load/charger for a few minutes to reset. |
| Rafhlaða tæmist ekki | BMS protection triggered (over-discharge, overcurrent, high temperature), loose connections | Check all connections. Reduce load if overcurrent. Allow battery to cool down if too hot. Recharge the battery if it's in over-discharge protection. |
| Minnkuð afkastageta/keyrslutími | Aging battery, improper charging, extreme operating temperatures | Tryggið rétta hleðslugetutage and current. Operate within recommended temperature ranges. If battery is very old, consider replacement. |
Ef vandamálið heldur áfram eftir að þessar lausnir hafa verið prófaðar, vinsamlegast hafið samband við þjónustuver PowMr.
9. Tæknilýsing
| Parameter | Gildi |
|---|---|
| Vörumerki | PowMr |
| Fyrirmynd | 12.8V 100Ah |
| Tegund rafhlöðu | LiFePO4 (litíum járnfosfat) |
| Nafnbinditage | 12.8V |
| Nafngeta | 100 Ah |
| Orka | 1280Wh |
| Max. Hleðsla Voltage | 14.6V |
| Hámark Stöðugur hleðslustraumur | 50A |
| Hámark Stöðugur losunarstraumur | 100A |
| Innbyggt BMS | 100A |
| Cycle Life | 4000+ cycles (100% DoD) |
| Mál (L*B*H) | 325*170*215mm (12.79"D x 6.69"W x 8.46"H) |
| Þyngd | 11.5 kg |
| Tegund flugstöðvar | M8 flugstöð |
| Vatnsheld einkunn | IP65 |
| Hleðsluhitastig | 0°C til 50°C |
| Afhleðsluhitastig | -20°C til 60°C |
| Geymsluhitastig | -10°C til 50°C |
Image: The PowMr 12.8V 100Ah LiFePO4 battery displayed alongside a table summarizing its key technical specifications.
10. Ábyrgð og stuðningur
Fyrir upplýsingar um ábyrgð, tæknilega aðstoð eða fyrirspurnir um þjónustu, vinsamlegast vísið til opinberu PowMr. webvefsíðu eða hafðu samband við þjónustuver þeirra beint. Geymdu kaupkvittunina sem sönnun fyrir kaup vegna ábyrgðarkröfu.
PowMr Official Websíða: www.powmr.com
