1. Inngangur
Welcome to the Bernette B35 Sewing Machine user manual. This guide provides essential information for setting up, operating, and maintaining your new sewing machine. The Bernette B35 is a mechanical sewing machine designed for beginners and hobbyists, offering reliability and simplicity for various sewing projects, from clothing to quilting and crafts.
Mikilvægar öryggisleiðbeiningar:
- Takið alltaf tækið úr sambandi við rafmagnsinnstunguna strax eftir notkun og áður en það er þrifið, hlífar fjarlægðar eða aðrar viðhaldsleiðréttingar gerðar af notanda.
- Do not allow children to operate the machine without supervision.
- Haltu fingrum frá öllum hreyfanlegum hlutum. Sérstakrar varúðar er krafist í kringum saumavélarnálina.
- Use the correct needle plate. The wrong plate can cause the needle to break.
- Ekki nota bognar nálar.
- Ekki toga í eða ýta á efnið á meðan þú saumar. Það gæti beygt nálina og valdið því að hún brotni.
- Slökkvið á saumavélinni þegar þið gerið einhverjar stillingar á nálarsvæðinu, eins og að þræða nálina, skipta um nál, þræða spóluna eða skipta um saumfæt.
2. Innihald pakka
Your Bernette B35 Sewing Machine package includes the following items:
- Bernette B35 Sewing Machine
- Fótpedali
- 7 Presser Feet (Zigzag, Buttonhole, Zipper, Satin, etc.)
- Spólur
- Nálasett
- Saumaskurður
- Skrúfjárn
- Lópensill
- Spool Holders
- Rykhlíf
- Leiðbeiningarhandbók
- Additional accessories may include: Rotary Cutting Mat, Rotary Cutter, Non-slip Frosted Acrylic Ruler, Tailor Scissors, Needle Threader.
3. Uppsetning
3.1 Upptaka og staðsetning
Carefully remove the machine from its packaging. Place the machine on a stable, flat surface. Ensure there is adequate lighting and space for your sewing projects.
3.2 Rafmagnstenging
Connect the foot pedal cord to the machine's power socket. Plug the power cord into a suitable electrical outlet. Ensure the machine's power switch is in the "OFF" position before connecting.
3.3 Að vinda spóluna
Follow these steps to wind the bobbin correctly:
- Settu þráðsnúðu á keflispinna.
- Leiðið þráðinn í gegnum efri tvinnaleiðarann og í kringum spennudiskinn á spólunni.
- Setjið tóma spólu á spóluvindarann.
- Wind the thread clockwise a few times around the bobbin.
- Ýttu spóluvindarsnælunni til hægri.
- Gently press the foot pedal to start winding. The machine will stop automatically when the bobbin is full.
- Klippið þráðinn og ýtið spólubúnaðinum aftur til vinstri.
Mynd: Nærmynd view of the bobbin winding area on the Bernette B35 sewing machine, showing the bobbin case and thread path.
3.4 Að þræða efri þráðinn
Proper threading is crucial for good stitch quality. Follow the numbered guides on the machine:
- Lyftu þrýstifótastiganum.
- Setjið þráðspóluna á spólupinnann.
- Leiðið þráðinn í gegnum efri tvinnaleiðarann.
- Bring the thread down through the right channel, around the tension discs, and up through the left channel.
- Krækið þráðinn í þráðgjafann frá hægri til vinstri.
- Guide the thread down through the remaining guides to the needle.
- Þræðið nálina að framan og aftan.
Mynd: Ítarleg view of the Bernette B35 sewing machine's needle area, illustrating the correct upper thread path and the needle threader mechanism.
3.5 Að setja spóluna í
After winding, insert the bobbin into the bobbin case and then into the machine's bobbin compartment. Ensure the thread feeds smoothly from the bobbin.
3.6 Að festa saumfótinn
To change a presser foot, raise the presser foot lifter. Press the release lever at the back of the presser foot holder to detach the current foot. Align the new presser foot with the pin on the holder and lower the presser foot lifter until it snaps into place.
4. Notkunarleiðbeiningar
4.1 Val á saumum
The Bernette B35 offers 23 built-in stitches. Use the stitch selector dial on the front of the machine to choose your desired stitch pattern. Refer to the stitch chart printed on the machine for available options.
Mynd: Framan view of the Bernette B35 sewing machine, highlighting the stitch selection dial and the stitch pattern chart.
4.2 Að stilla sporlengd og sporbreidd
Use the dedicated dials to adjust the stitch length and width according to your fabric and project requirements. Shorter stitch lengths are for stronger seams, while longer lengths are for basting or decorative stitches. Stitch width controls the zigzag or decorative stitch spread.
4.3 One-Step Automatic Buttonhole
The B35 features a convenient one-step automatic buttonhole function. Attach the buttonhole presser foot, place the button in the foot's holder, and select the buttonhole stitch. The machine will automatically sew all four sides of the buttonhole to the correct size.
4.4 Using Different Presser Feet
Your machine comes with 7 snap-on presser feet for various tasks:
- Zigzag Foot: Standard foot for most sewing tasks.
- Rennilásfótur: For sewing zippers and cording.
- Fótur fyrir hnappagat: For creating automatic buttonholes.
- Satin Stitch Foot: For dense decorative stitches.
- Consult your machine's accessory guide for specific uses of all 7 included feet.
Image: A person operating the Bernette B35 sewing machine, demonstrating its compact design and ease of use for various projects.
5. Viðhald
Regular maintenance ensures the longevity and optimal performance of your Bernette B35.
5.1 Þrif
- Taktu alltaf vélina úr sambandi áður en þú þrífur.
- Use the provided lint brush to remove lint and dust from the bobbin area and feed dogs.
- Wipe the exterior of the machine with a soft, dry cloth. Do not use harsh chemicals.
5.2 Nálarskipti
Change the needle regularly, especially after 8-10 hours of sewing or if it becomes bent or dull. A dull needle can cause skipped stitches or fabric damage. Use only needles suitable for home sewing machines.
5.3 Smurning
The Bernette B35 is designed for minimal lubrication. Refer to the full instruction manual for specific lubrication points if required, or consult an authorized service center.
6. Bilanagreining
Hér eru lausnir á algengum vandamálum sem þú gætir lent í:
| Vandamál | Möguleg orsök | Lausn |
|---|---|---|
| Sleppti sauma | Röng nál, beygð nál, röng þræðing. | Skiptu um nál, þræðiðu vélina aftur og vertu viss um að nálin sé rétt sett í. |
| Þráður slitinn | Incorrect tension, poor quality thread, bent needle, improper threading. | Adjust tension, use good quality thread, change needle, re-thread. |
| Efnið nærist ekki | Feed dogs lowered, presser foot pressure too low. | Raise feed dogs, increase presser foot pressure. |
| Vélin fer ekki í gang | Power cord not plugged in, foot pedal not connected, power switch off. | Athugaðu allar tengingar, vertu viss um að kveikt sé á rofanum. |
If you encounter persistent issues, please refer to the comprehensive troubleshooting section in your full instruction manual or contact Bernette customer support.
7. Tæknilýsing
Key technical specifications for the Bernette B35 Sewing Machine:
- Gerð: B35
- Vörumerki: Bernette
- Vörumál: 11.8 x 14 x 17.1 tommur (29.97 x 35.56 x 43.43 cm)
- Þyngd hlutar: 15.8 pund (7.17 kg)
- Efni: Málmgrind
- Litur: Hvítur
- Aflgjafi: AC (Electric)
- Innbyggðir saumar: 23 (Utility and Decorative)
- Presser Feet Included: 7
- Tegund hnappagat: One-Step Automatic
- Lýsing: LED
Image: Illustration highlighting the heavy-duty metal frame construction and LED lighting feature of the Bernette B35 sewing machine.
Image: The Bernette B35 sewing machine shown with an extension table, emphasizing its suitability for everyday sewing and repairs, and providing extra workspace.
8. Vöru lokiðview Myndband
Horfðu á þetta opinbera vörumyndband til að fá ítarlega yfirsýnview of the Bernette B35 Sewing Machine's features and basic operation.
Myndband: Ítarleg vara yfirview of the Bernette B35 Sewing Machine, demonstrating its various functions and capabilities.
9. Ábyrgð og stuðningur
The Bernette B35 Sewing Machine comes with a manufacturer's warranty. Please refer to the warranty card included in your package for specific terms and conditions, including coverage duration and claim procedures.
For technical support, service, or to purchase genuine Bernette accessories, please visit the official Bernette website or contact an authorized Bernette dealer. Keep your purchase receipt as proof of purchase for warranty claims.
Tilföng á netinu: For additional tutorials and FAQs, visit the official Bernette support page: www.bernette.com/en-US/Support
